Borunte BRTIRUS0805A Rūpnieciskais Robots

BRTIRUS0805A Six-Axis Industrial Robot

Short Description
The BRTIRUS0805A is a compact and high-performance six-axis industrial robot developed by BORUNTE. It is designed for precision tasks and efficient automation in a wide range of industrial applications.

Product Overview

The BRTIRUS0805A robot features a simple and reliable control system combined with a compact mechanical structure. It delivers high positioning accuracy and excellent dynamic performance, making it an ideal solution for modern automated production environments.

With a payload capacity of 5 kg and an arm reach of 990 mm, this robot is particularly well-suited for applications such as injection molding, pick-and-place operations, stamping, material handling, machine tending, loading and unloading, and assembly tasks.

The robot is optimized for use with injection molding machines ranging from 30T to 250T, ensuring flexibility and efficiency in manufacturing processes.

Key Features

• High precision with repeatability of ±0.05 mm

• Compact design for space-saving installation

• Excellent dynamic performance

• User-friendly and reliable control system

• Suitable for a wide range of industrial applications

Technical Specifications

• Robot Type: Six-axis industrial robot

• Arm Length: 990 mm

• Payload Capacity: 5 kg

• Repeatability: ±0.05 mm

• Power Supply: 3.67 kVA

• Protection Rating:

  • Wrist: IP54

  • Body: IP40

Applications

• Injection molding

• Pick-and-place operations

• Stamping

• Material handling

• Machine tending (loading/unloading)

• Assembly processes
