Röders 3 Asu frēzēšanas un slīpēšanas centrs RPT600

Machining range630 mm x 530 mm x 300 mmTable size600 mm x 500 mm, T‑slots 14 mmClamping unitErowa UPC / System 3R Dynafix / Parotec Power Grip 160Workpiece weightmax. 400 kgFeed0–60,000 mm/minMilling spindle (standard)42,000 rpm, 14 kW, HSK E40,

maximum tool diameter 16 mm, others on request
Tool changer42 or 87 places for HSK E40,
optional larger changer available,
integrated measuring laserChip disposalWith 2 screws into chip box behind the machine
or with additional chip conveyorMachine weight~8.8 tRequired spaceW 2200 mm x L 2500 mm x H 2540 mm
